Bellmouth Collars
Description
Metal Zinc’s Bellmouth Collar is used for medium and high pressure applications to aid in air distribution from square trunk line
Features
- EE version with Handle, 2’’ Standoff and 3/8’’ Aluminum Rod
- VD version with spring loaded damper and small handle
- One piece spun design
- ⅛’’x1’’ double sided neoprene gasket
Standard Construction
- Manufactured with spun down 16-gauge galvanized steel G60 material ASTM A653
- Crimp and bead
- Factory punched screw holes
Optional Construction
- Damper blade with zero-leak snap-in brushing
- G90 Galvanized
Product specifications
| Metal Zinc Part Number | Size A Inches | Gauge | Row Quantity | Pallet Quantity |
|---|---|---|---|---|
| SF0355-(EE/VD) | 4 | 16 | Made to Order | Made to Order |
| SF0375-(EE/VD) | 6 | 16 | 20 | 360 |
| SF0395-(EE/VD) | 8 | 16 | 16 | 288 |
| SF0415-(EE/VD) | 10 | 16 | 12 | 216 |
| SF0425-(EE/VD) | 12 | 16 | 8 | 144 |
| SF0435-(EE/VD) | 14 | 16 | 6 | 108 |
| SF0445-(EE/VD) | 16 | 16 | Made to Order | Made to Order |
