Sheet Metal Access Door Tab Lock Frame
Sheet Metal Access Door Tab Lock Frame
Description
Metal Zinc’s Sheet Metal Access Door with Tab Lock Frame is used to access the inside of sheet metal rectangular ductwork
Features
- Double panelled with front and back metal plates and 1½” insulation
- Meets 2005 SMACNA Standards for pressure class and gauges (Refer to page 7.2; figure 7-2)
- Regular doors can be used up to 4” water gauge
- Tab lock frame easily bends over sheet metal
Standard Construction
- Door panel is manufactured from 24-gauge galvanized steel ASTM A653. Panels mechanically locked together.
- Insulation is 1½” high-density fiberglass insulation UL Classifications; FHC25/50, ASTM C 1071; Type 1 ASTM G 21, Greenguard Indoor Air Quality Certified, Greenguard Children and Schools, NFPA 90A and 90B.
- Gasket is closed-cell neoprene, UL94HF1 listed with service temperature range of 20º F to 200º F. The gasket is bonded to the inside of the frame.
- Dovetail Frame measuring “6 x 6” to 12” x 12” are manufactured from 26-gauge galvanized steel. Frames measuring 14” x 14” to 24” x 24” are manufactured from 24-gauge galvanized steel.
- All frames are manufactured with spot welds at each corner for increased strength and improved dovetail design for easy installation on metal ducts.
- Cams & Strikes: The cam is stamped using 16-gauge galvanized steel. The latch is stamped from 20-gauge galvanized steel. Each cam is secured to the door with a rivet. The latch is secured to the frame in two locations for added rigidity.
Optional Construction
- Additional cams
- Aluminum
- Galvanneal (paint grip)
- Neoprene gasket bonded outside the frame
- PCD
- Stainless steel 304 and 316
Product specifications
| Metal Zinc Part Number | Size A & B | Gauge | Number of Cams | Bundle Quantity | Pallet Quantity |
|---|---|---|---|---|---|
| AD0010-TB | 6 x 6 | 24 | 2 | 10 | TBD |
| AD0020-TB | 8 x 8 | 24 | 2 | 10 | 720 |
| AD0030-TB | 10 x 10 | 24 | 2 | 10 | 396 |
| AD0040-TB | 12 x 12 | 24 | 2 | 10 | 294 |
| AD0050-TB | 14 x 14 | 24 | 2 | 10 | TBD |
| AD0060-TB | 16 x 16 | 24 | 4 | 10 | TBD |
| AD0070-TB | 18 x 18 | 22 | 4 | 10 | TBD |
| AD0080-TB | 20 x 20 | 22 | 4 | 10 | TBD |
| AD0100-TB | 22 x 22 | 22 | 4 | 10 | TBD |
| AD0110-TB | 24 x 24 | 22 | 4 | 10 | TBD |
