Heavy Duty Press On Conical Tap
Description
Metal Zinc’s Two Piece Conical tap with heavy duty damper is used for low and medium pressure applications.
Features
- Welded seams for low leakage and added strength
- 2” Standoff and 3/8” Aluminum Square Rod on Damper Hardware
- Pressure Rating – Designed Per SMACNA 3rd Edition
Standard Construction
- Body and Collar- Formed using G60, 24-gauge ASTM A-653 material
- 1/8” x 1” Two Sided Neoprene Gasket
- 1” flange
Optional Construction
- Orange Adjustable Handles
- Damper Blade with Zero-lock Snap in Bushing
- G90 Galvanized Steel
- Spin-in (-SI) Version available
Product specifications
| Metal Zinc Part Number | Size A Inches | Bundle Quantity | Pallet Quantity |
|---|---|---|---|
| SF0775-EE | 4 | 30 | 210 |
| SF0785-EE | 6 | 16 | 112 |
| SF0795-EE | 8 | 12 | 84 |
| SF0805-EE | 10 | 10 | 70 |
| SF0810-EE | 12 | 8 | 56 |
| SF0845-EE | 14 | 5 | 35 |
| SF0823-EE | 16 | 5 | 35 |
